Use the EXPLODE command to remove all blocks and nested blocks from the DWG file.

Navigate to the INSERT tab, and ensure there are no blocks or block definitions in the DWG file.

Turn on and thaw all layers in the DWG file, and delete all unsupported objects from all layers in the DWG file.

Use the WBLOCK command to create a block of your DWG and then save that block as a DWG file.

In AutoCAD, use the following methods to remove any unsupported objects. You'll see the following warning message:įusion 360 removes any fields, 3D geometry, custom objects, and geoloction objects automatically. If your DWG file contains any blocks, nested blocks, block definitions, or xrefs, it won't insert.

Custom objects (including AEC objects and proxy objects).

Organizations Name and Mailing Address The next block that you will create contains the organizations name and mailing address.

Blocks (including nested blocks and block definitions) For ease, just add the additional reference to the packages title print, which is usually the first print, showing the sheet number and name.

The following AutoCAD objects are not supported, even if they are on layers that are frozen or turned off: In AutoCAD, remove any unsupported objects from the DWG file before you use it to create a new title block in Fusion 360. When you save your DWG file, make sure the file name is unique, and doesn't match the name of any existing title blocks in your Fusion 360 drawing.

Set the border size in AutoCAD so that it matches the sheet size in the Fusion 360 drawing.

Create geometry and text for the border.

In AutoCAD, you can create border geometry to include in your Fusion 360 drawing.

Note: When you include an image as part of a title block, Fusion 360 adds a border around the image. Prompts are the text that displays canvas in Fusion 360, to identify the attribute.ĭefault is the attribute value that displays by default. Tags identify the location of the text in the drawing and only display in AutoCAD. The Attribute Definition dialog displays. In AutoCAD, create attribute definitions in the DWG file.Īt the command line in AutoCAD, enter the ATTDEF command. Attribute definitionsĪlthough you can create attributes directly in the Title Block contextual environment, Fusion 360 recognizes AutoCAD attributes, and converts them into Fusion 360 attributes. In AutoCAD, make sure the bottom right corner of your title block is located at the WCS origin point (0,0) in model space. In AutoCAD, make sure the title block geometry, text, attributes, and images are all located in model space, not paper space.

#AUTOCAD TITLE BLOCK PDF#

Exporting the layout as a PDF generates a layout with the desired title block.You can use a DWG file created in AutoCAD to create a custom title block in Fusion 360.īefore you do this, you need to ensure the geometry, text, attributes, and images in the DWG file are compatible, so that they will insert smoothly into the Drawing workspace in Fusion 360. Alternatively, add the CAD layout elements, including the title block to a data frame in ArcMap and other working CAD, to another data frame. For more information, refer to ArcMap: A quick tour of page layouts. For more information, refer to the following Help document, ArcMap: Adding CAD data to a map.Ī title block can also be recreated using the tools in the Insert menu or Draw toolbar. This allows the title block to be displayed in ArcMap as a GIS feature. If the title block is in the paper space, copy the title block from the paper space into the model space of the CAD drawing. ArcGIS for Desktop only reads the entities within the AutoCAD model space. Is it possible to insert a CAD title block to an ArcMap layout?Ī title block can be displayed in ArcMap if the block is in the model space of the AutoCAD drawing. FAQ: Is it possible to insert a CAD title block to an ArcMap layout? Question
